THE BrixMeister ys

Fusion of refractive index and angle of optical rotation
- Making the invisible, visible -

Portable Refracto Polarimeter

Portable Refracto Polarimeter

RePo series

JP
PAT# 4480653
PAT# 6435532
1511001, 1511002
US
PAT# 9,709,489 B2
US D749969S
US D750571S
CN
PAT# ZL 2015 8 0000371.2
ZL 2014 3029 3095.1
EUIPO
002520825-0001
002520825-0002
TW
D171453, D171454
KR
30-0796571, 30-0796572,
10-2205783
SDGs

RePo series Four points

Point 1２ in １

Brix alone can only indicate the overall amount of dissolved solids in a solution. With REPO-1, it is possible to determine if a product has been adulterated by measuring the optical rotation. For example, fructose rotates light to the left while glucose rotates light to the right. If a sample has been adulterated with glucose, it will make the optical rotation readings appear more positive than a pure solution.

2 in 1

Point 2Compact size

Great portability,
10.1×16.0×3.8cm
and weighs only 325g

Compact size

Point 3Automatically calculated scales

Press "User" to select the desired scale: Purity, International Sugar Scale, Specific Rotation, and Concentration.

Automatically calculated scales

Point 4Measurement evaluation indicator

Measurements are evaluated against pre-set tolerancelimits, and the result is indicated by green or red light.
(Upper and lower tolerance limits must be set in advance to using this function)

Measurement evaluation indicator

RePo series Features

Features and design that Atago's commitment created

RePo series Features

Application Examples

Sugar industries

Sugar industries

Analyzing fragrances

Analyzing fragrances

Analyzing inverted sugar syrups

Analyzing inverted sugar syrups

Honey industries

Honey industries

Medicine

Medicine

RePo series Measuring Method

サンプルステージ

❶ Fill the sample stage up to the fill line (approx. 3mL).

スタート

❷ Press START.

測定結果

❸ Measurement is displayed.

RePo Series [Product details]

Portable Refracto-Polarimeter RePo-1

RePo-1 $1,500.00 USD
拡大画像

A fusion of index of refraction and angle of optical rotation making the invisible,visible.

Brix can only indicate the overall amount of dissolved solids in a solution. With REPO-1, it is possible to determine if a product has been adulterated by measuring the optical rotation. Announcing an All-in-One, refractometer and polarimeter hybrid unit. As little as 3mL sample, Repo-1 can measure both brix and optical rotation of the sample. With the press of a button, purity, international sugar scale, specific rotation, and concentration can be displayed. Users can also set an upper and lower measurement limit. An indicator light alerts the user if a measurement value is within the limits, allowing for optimal efficiency.“Could a Repo-1 be used in our field?” “How about for my unique application?”We look forward to hearing from you!
Specifications
Model RePo-1
Cat.No. 5010
Measurement Readings Angle of rotation,International Sugar Scale,purity,Specific Rotation,Concentration,Brix,Temperature
Range Angle of Rotation:-5.00 -5.00°
*Convertible to -25.00°to +25.00°with a 100mm observation tube
*Convertible to -50.00° to +50.00°with a 200mm observation tube
International Sugar Scale: -130 to +130°Z
Brix: 0 to 85%
Temperature: 15.0 to 40.0℃
Resolution Angle of Rotation: 0.01°
Brix: 0.1%
International Sugar Scale: 0.1°Z
Temperature: 0.1°C
Accuracy Angle of Rotation: ±0.1°(20℃）
International Sugar Scale:3°Z,
Brix: ±0.2%
Temperature: ±1℃
Temperature compensation Brix: 15 to 40℃,
Purity: 18 to 40℃,
International Sugar Scale: 18 to 40℃
Light source LED
Measurement Time 12 seconds
Power Supply Size AAA alkaline battery x 4
International Protection Class IP67

· Standard liquid Repo-series : RE-99110

· MAGIC™ for RePo : RE-79000

· RePo Small Volume Adapter : RE-72093
RePo-1

Portable Refracto-Polarimeter RePo-1

Close

Portable Refracto-Polarimeter RePo-2

RePo-2 $1,500.00 USD
拡大画像

The RePo-2 can determine the amount of fructose (%) in HFCS.

Like the RePo-1, the RePo-2 is a two-in-one refractometer and polarimeter hybrid.In addition to angle of rotation and Brix, the RePo-2 also converts and displays the amount of fructose (%) within HFCS. The RePo-2 is ideal for various industries such as food and beverage, or sugar refining.
Specifications
Model RePo-2
Cat.No. 5012
Measurement Readings Angle of Rotation,Brix,Fructose % at HFCS,Temperature
Range Angle of Rotation:-5.00 to +5.00°
*Convertible to -25.00°to +25.00°with a 100mm observation tube
*Convertible to -50.00° to +50.00°with a 200mm observation tube
Brix : 0.0 to 85.0%
Fructose % : 0.0 to 99.9%
Temperature: 15 to 40℃
Resolution Angle of Rotation : 0.01°
Brix : 0.1%
Fructose : 0.1%
Temperature : 0.1℃
Accuracy Angle of Rotation: +-0.1°(20℃）
Brix :+-0.2%
Temperature: +-1℃
Temperature compensation Brix:15 to 40℃
Light source LED
Measurement Time 12 seconds
Power Supply Size AAA alkaline battery x4
International Protection Class IP67

· Standard liquid Repo-series : RE-99110

· MAGIC™ for RePo : RE-79000

· RePo Small Volume Adapter : RE-72093
RePo-2

Portable Refracto-Polarimeter RePo-2

Close

Portable Refracto-Polarimeter RePo-3

RePo-3 $1,500.00 USD
拡大画像

The RePo-3 can determine the amount of invert sugar (%) converted from sucrose.

In addition to angle of rotation and Brix, the RePo-3 also converts and displays the amount of invert sugar (%) derived from sucrose. The RePo-3 is ideal for various industries such as sugar refining.
Specifications
Model RePo-3
Cat.No. 5013
Measurement Readings Angle of Rotation,Brix,
Invert ratio % at Inverted sugar,
Temperature
Range Angle of Rotation:-5.00 to +5.00°(*)
*Convertible to -25.00°to +25.00°with a 100mm observation tube
*Convertible to -50.00° to +50.00°with a 200mm observation tube
Brix:0.0 to 85.0%
Invert ratio% of sucrose:0.0 to 99.9%
Temperature: 15.0 to 40.0℃
Resolution Angle of Rotation : 0.01°
Brix : 0.1%
Invert ratio : 0.1%
Temperature : 0.1℃
Accuracy Angle of Rotation : ±0.1° (20℃)
Brix : ±0.2%
Temperature : ±1℃
Temperature compensation Brix ： 15 to 40℃
Light source LED
Measurement Time 12 seconds
Power Supply Size AAA alkaline battery x4
International Protection Class IP67

· Standard liquid Repo-series : RE-99110

· MAGIC™ for RePo : RE-79000

· RePo Small Volume Adapter : RE-72093
RePo-3

Portable Refracto-Polarimeter RePo-3

Close

Portable Refracto-Polarimeter RePo-4

RePo-4 $1,500.00 USD
拡大画像

The RePo-4 can determine the amount of fructose (%) and honey moisture (%).

In addition to angle of rotation and Brix, the RePo-4 also converts and displays the amount of fructose (%) and honey moisture (%). The RePo-4 is ideal for total quality control of honey.
Specifications
Model RePo-4
Cat.No. 5014
Measurement Readings Angle of Rotation,Brix,
Temperature,Fructose% of honey, Honey Moisture %
Range Angle of Rotation:-5.00 to +5.00°(*)
*Convertible to -25.00°to +25.00°with a 100mm observation tube
*Convertible to -50.00° to +50.00°with a 200mm observation tube
Brix: 0.0 to 85.0%
Fructose % : 0.0 to 99.9%
Honey Moisture % : 13.0 to 30.0%
Temperature : 15.0 to 40.0℃
Resolution Angle of Rotation : 0.01°
Brix : 0.1%
Fructose % : 0.1%
Honey Moisture % : 0.1%
Temperature : 0.1℃
Accuracy Angle of Rotation : ±0.1° (at 20℃)
Brix : ±0.2%
Honey Moisture % : ±0.2%
Temperature : ±1℃
Temperature compensation Brix ：15 to 40℃
Honey Moisture % : 15 to 40℃
Light source LED
Measurement Time 12 seconds
Power Supply Size AAA alkaline battery x4
International Protection Class IP67

· Standard liquid Repo-series : RE-99110

· MAGIC™ for RePo : RE-79000

· RePo Small Volume Adapter : RE-72093
RePo-4

Portable Refracto-Polarimeter RePo-4

Close

Portable Refracto-Polarimeter RePo-5

RePo-5 $1,500.00 USD
拡大画像

The RePo-5 can determine refractive index(nD).

In addition to angle of rotation and Brix, the RePo-5 can also display the refractive index (nD) of a sample. The RePo-5 is ideal for quality control in various industries such as fragrances, cosmetics, or pharmaceutical.RePo-5 satisfies Pharmacopoeia standards.
Specifications
Model RePo-5
Cat.No. 5015
Measurement Readings Angle of Rotation, Brix,
Refractive index,Temperature
Range Angle of Rotation:-5.00 to +5.00°
*Convertible to -25.00°to +25.00°with a 100mm observation tube
*Convertible to -50.00° to +50.00°with a 200mm observation tube
Brix: 0.0 to 85.0%
Refractive index:1.3306～1.5050
Temperature: 15.0 to 40.0℃
Resolution Angle of Rotation : 0.01°
Brix : 0.1%
Refractive index : 0.0001
Temperature : 0.1℃
Accuracy Angle of Rotation: ±0.1° (20℃)
Brix：±0.2%
Refractive index:±0.0002 (20℃)
Temperature: ±1℃
Temperature compensation Brix ： 15 to 40℃
Light source LED
Measurement Time 12 seconds
Power Supply Size AAA alkaline battery x4
International Protection Class IP67

· Standard liquid Repo-series : RE-99110

· MAGIC™ for RePo : RE-79000

· RePo Small Volume Adapter : RE-72093

· RePo Reduced Optical Path Adapter 5mm : RE-72094

· RePo Reduced Optical Path Adapter 5mm(Adapter only) : RE-72095

· RePo Reduced Optical Path Adapter 5mm(Glass Cell only) : RE-72096

· RePo Reduced Optical Path Adapter 10mm : RE-72097

· RePo Reduced Optical Path Adapter 10mm(Adapter only) : RE-72098

· RePo Reduced Optical Path Adapter 10mm(Glass Cell only) : RE-72099
RePo-5

Portable Refracto-Polarimeter RePo-5

Close

Package RePo-1 Type A Recommended for sugar industry

RePo-1 $1,600.00 USD
拡大画像
A package for the RePo-1 that includes syringes and single-use, disposable filters.
By using a syringe and a disposable filter, it is possible to measure stabilized values of substances such as raw sugar and other materials.
These accessories are also sold separately.
Specifications
Model RePo-1 Type A Recommended for sugar industry
Cat.No. 5020
Package Contents ・RePo-1 (Main unit)
・Beaker 100mL
・Syringe Filter Orange 45 (50pcs)
・Syringe 20mL (3pcs)
・Easy Filter (100pcs)

· MAGIC™ for RePo : RE-79000

· Beaker 100mL : RE-79423

· Syringe Filter Orange 45 (100pcs) : RE-79420

· Syringe 20mL (3pcs) : RE-79421

· Easy Filter (100pcs) : RE-79422

· RePo Small Volume Adapter : RE-72093
