Digital Refractometer | ATAGO CO.,LTD.

Model
PR-32α	Brix0.0～32.0％
PR-101α	Brix0.0～45.0％
PR-201α	Brix0.0～60.0％
PR-301α	Brix45.0～90.0％
PR-RI	Refractive Index
PR-60PA	Isopropyl alcohol
PR-50HO	H₂O₂
PET-109	Ethyl alcohol
PR-100SA	Sea water
PR-40DMF	DMF Dimethylformamide
PR-BUTYRO	BUTYRO
UG-α	Urine S.G
WM-7	Wine
PR-Plato	Plato

Digital Refractometer PR-32α (alpha)

This model is suitable for fruits juice, food and beverage as well as chemicals and industrial liquids such as cutting oil, cleaning liquid.The unit is programmed with the user-scale feature which allows to input the coefficient to display the concentrations direcly. Also, it is equipped with ELI function for the accurate measurements with confidence even at outside.

Specifications

Model	PR-32α
Cat.No.	3405
Range	Brix : 0.0 to 32.0%
Accuracy	±0.1%
Temperature compensation	5 to 40°C
Power Supply	006P dry battery (9V)
Dimensions & Weight	17×9×4cm, 270g

Accessories

· SUPER EXTRACTOR : RE-29401

· 10% Sucrose (±0.03%) : RE-110010

· 20% Sucrose (±0.03%) : RE-110020

· 30% Sucrose (±0.03%) : RE-110030

* Calibration Certificate : Contact an ATAGO representative for details.

Digital Refractometer PR-101α

This model is suitable for fruits juice, food and beverage as well as chemicals and industrial solutions such as cutting oil, cleaning liquid.The unit is programmed with the user-scale feature which allows to input the coefficient to display the concentrations direcly. Also, it is equipped with ELI function for the accurate measurements with confidence even at outside.

Specifications

Model	PR-101α
Cat.No.	3442
Range	Brix : 0.0 to 45.0%
Resolution	0.1%
Accuracy	±0.1%
Temperature compensation	5 to 40°C
Power Supply	006P dry battery (9V)
Dimensions & Weight	17×9×4cm, 270g

Accessories

· SUPER EXTRACTOR : RE-29401

· 10% Sucrose (±0.03%) : RE-110010

· 20% Sucrose (±0.03%) : RE-110020

· 30% Sucrose (±0.03%) : RE-110030

· 40% Sucrose (±0.04%) : RE-110040

* Calibration Certificate : Contact an ATAGO representative for details.

Digital Refractometer PR-201α

It is suitable for various samples up to Brix 60% including jams, concentrated juices and lubricant.The unit is programmed with the user-scale feature which allows to input the coefficient to display the concentrations direcly. Also, it is equipped with ELI function for the accurate measurements with confidence even at outside.

Specifications

Model	PR-201α
Cat.No.	3452
Range	Brix : 0.0 to 60.0%
Resolution	0.1%
Accuracy	±0.1%
Temperature compensation	10 to 40°C
Power Supply	006P dry battery (9V)
Dimensions & Weight	17×9×4cm, 270g

Accessories

· 10% Sucrose (±0.03%) : RE-110010

· 20% Sucrose (±0.03%) : RE-110020

· 30% Sucrose (±0.03%) : RE-110030

· 40% Sucrose (±0.04%) : RE-110040

· 50% Sucrose (±0.05%) : RE-110050

· 60% Sucrose (±0.05%) : RE-110060

* Calibration Certificate : Contact an ATAGO representative for details.

Digital Refractometer PR-301α

It is suitable for higher concentration like jellies, raw liquid sugar, etc.The unit is programmed with the user-scale feature which allows to input the coefficient to display the concentrations direcly. Also, it is equipped with ELI function for the accurate measurements with confidence even at outside.

Specifications

Model	PR-301α
Cat.No.	3462
Range	Brix : 45.0 to 90.0%
Resolution	0.1%
Accuracy	±0.1%
Temperature compensation	10 to 40°C
Power Supply	006P dry battery (9V)
Dimensions & Weight	17×9×4cm, 270g
Included Accessories	Standard liquid LG

Accessories

· 50% Sucrose (±0.05%) : RE-110050

· 60% Sucrose (±0.05%) : RE-110060

* Calibration Certificate : Contact an ATAGO representative for details.

Parts

· Standard liquid LG (7mL) with round sheet : RE-9325

Digital Refractometer PR-RI

It is suitable for measuring the refractive indices of liquid samples in pharmaceutical and chemical products.When the start key is pressed after placing some droplets of sample on the prism, the refractive index and temperature will be displayed.

Specifications

Model	PR-RI
Cat.No.	3480
Range	Refractive index : 1.3306 to 1.4436 Temperature 5 to 45°C
Resolution	0.0001
Accuracy	±0.0002 (water at 20°C)
Ambient Temperature	10 to 40°C
Power Supply	006P dry battery (9V)
Dimensions & Weight	17×9×4cm, 270g

Accessories

* Calibration Certificate : Contact an ATAGO representative for details.

Digital Refractometer for Isopropyl alcohol PR-60PA

The concentration of isopropyl alcohol used for cleaning, wetting in printout and other uses can be measured with only a small quantity of sample and with a simple procedure.The temperature is automatically corrected and not necessary to worry about the temperature.

Specifications

Model	PR-60PA
Cat.No.	3477
Scale	Concentration of isopropyl alcohol
Range	0.0 to 60.0% (W/W)
Resolution	0.1%
Accuracy	0 to 30%:±0.5% Around 40%:±0.8% Around 60%:±1.6%
Temperature compensation	10 to 35°C
Power Supply	006P dry battery (9V)
Dimensions & Weight	17×9×4cm, 270g

Accessories

* Calibration Certificate : Contact an ATAGO representative for details.

Digital Refractometer for a Water Solution of Hydrogen Peroxide PR-50HO

The concentration of a water solution of hydrogen peroxide used as a disinfecting solution for cartons for soft drinks and milk-based drinks can be measured with only a small quantity of sample and with a simple procedure.The temperature is automatically corrected and not necessary to worry about the temperature.

Specifications

Model	PR-50HO
Cat.No.	3478
Scale	Concentration of a water solution of hydrogen peroxide
Range	0.0 to 50.0% (W/W)
Resolution	0.1%
Accuracy	±0.5%
Temperature compensation	5 to 40°C
Power Supply	006P dry battery (9V)
Dimensions & Weight	17×9×4cm, 270g

Accessories

* Calibration Certificate : Contact an ATAGO representative for details.

Digital Refractometer for Ethyl Alcohol PET-109

The concentration of ethyl alcohol used for foods, cleaning, cooling and other purposes can be measured with only a small quantity of sample and with a simple procedure.The temperature is automatically corrected and not necessary to worry about the temperature.

Specifications

Model	PET-109
Cat.No.	3486
Scale	Concentration of ethyl alcohol
Range	0.0 to 45.0% (W/W)
Resolution	0.1%
Accuracy	0 to 30%:±0.5% Around 40%:±0.8% Around 45%:±1.2%
Temperature compensation	10 to 35°C
Power Supply	006P dry battery (9V)
Dimensions & Weight	17×9×4cm, 270g

Accessories

* Calibration Certificate : Contact an ATAGO representative for details.

Digital Refractometer for Salinity PR-100SA

The salinity per mill (‰) of seawater can be measured with only a small quantity of sample and with a simple procedure. The temperature is automatically corrected and not necessary to worry about the temperature.

Specifications

Model	PR-100SA
Cat.No.	3488
Scale	Concentration of salinity
Range	0 to 100‰
Resolution	1‰
Accuracy	±2‰
Temperature compensation	5 to 40°C
Power Supply	006P dry battery (9V)
Dimensions & Weight	17×9×4cm, 270g

Accessories

* Calibration Certificate : Contact an ATAGO representative for details.

Digital Refractometer for Dimethylformamide PR-40DMF

The concentration of dimethylformamide used as a solvent for synthetic leather/fiber and gas refinement can be measured with only a small quantity of sample and with a simple procedure.The temperature is automatically corrected and not necessary to worry about the temperature.

Specifications

Model	PR-40DMF
Cat.No.	3489
Scale	Concentration of Dimethylformamide
Range	0.0 to 40.0% (W/W)
Resolution	0.1%
Accuracy	±0.3%
Temperature compensation	5 to 40°C
Power Supply	006P dry battery (9V)
Dimensions & Weight	17×9×4cm, 270g

Accessories

* Calibration Certificate : Contact an ATAGO representative for details.

Digital Butyro Refractometer PR-BUTYRO

New PR-BUTYRO perfect for Butter, Ghee & Edible Oil industry for checking purity / adulteration. PR-BUTYRO has dual scales of Butyro and Refractive Index.The temperature is automatically corrected and not necessary to worry about the temperature.

Specifications

Model	PR-BUTYRO
Cat.No.	3454
Range	Butyro : 30.0 to 90.0 RI : 1.4450 to 1.4850 (Converted at 40°C)
Resolution	Butyro: 0.1 RI : 0.0001
Accuracy	Butyro : ±0.5 (at 40°C) RI : ±0.0003 (at 40°C)
Temperature compensation	10 to 50°C
Power Supply	006P dry battery (9V)
Dimensions & Weight	17×9×4cm, 270g

Accessories

* Calibration Certificate : Contact an ATAGO representative for details.

Digital Urine S. G. Refractometer UG-α

This new Digital Urine Specific Gravity Refractometer UG-α (alpha) is an upgraded version of the late UG-1.After pressing the START key, with the sample placed on the prism, the measurement values will be displayed within 3 seconds.

Specifications

Model	UG-α
Cat.No.	3464
Range	Urine S.G. : 1.0000 to 1.0600
Resolution	0.0001
Accuracy	±0.0010
Temperature compensation	10 to 35°C
Power Supply	006P Dry battery (9V)
Dimensions & Weight	17×9×4cm, 270g

Accessories

* Calibration Certificate : Contact an ATAGO representative for details.

Digital Wine Refractometer WM-7

The WM-7 with 7 scales is a pocket Digital Wine Refractometer designed to operate of under the strictest environmental conditions, especially areas of high humidity of production and to measure concentration of grape must, easily, speedily, and accurately.Measurement of grape must concentration can be taken by winegrowers, wine cooperatives,wineries, buyers for grape must and so on.The measurement accuracy is upgraded to Brix ± 0.1%. Equipped with a new technology "External-Light-Interference" (E. L.I.)* that enable you to take accurate measurements with ease and confidence near at a window or outside.*Patent Pending

Specifications

Model	WM-7
Cat.No.	3415
Scale	Brix T.A. 1990 T.A. 1971 Oe (GER) Oe (Oechsle) KMW (or babo) Baume
Range	Brix (determined by ICUMSA) : 0.0 to 45.0% T.A. 1990 (Titre Alcoometrique established in 1990) : 0.0 to 26.0% T.A. 1971 (Titre Alcoometrique established in 1971) : 0.0 to 25.0% Oe (GER) (Oechsle used in Germany) : 0 to 240° Oe (Oechsle) : 0 to 240° KMW (or babo) : 0.0 to 40.0° Baume : 0.0 to 21.0°
Resolution	Brix (determined by ICUMSA) : 0.1% T.A. 1990 (Titre Alcoometrique established in 1990) : 0.1% T.A. 1971 (Titre Alcoometrique established in 1971) : 0.1% Oe (GER) (Oechsle used in Germany) : 1° Oe (Oechsle) : 1° KMW (or babo) : 0.1° Baume : 0.1°
Accuracy	Brix (determined by ICUMSA) : ± 0.1% T.A. 1990 (Titre Alcoometrique established in 1990) : ± 0.2% T.A. 1971 (Titre Alcoometrique established in 1971) : ± 0.2% Oe (GER) (Oechsle used in Germany) : ± 1° Oe (Oechsle) : ± 1° KMW (or babo) : ± 0.2° Baume : ± 0.2°
Temperature compensation	5 to 40°C (Automatic Temperature Compensation)
Ambient Temperature	5 to 40°C
Measurement Time	3 seconds
Power Supply	006P dry battery (9V)
International Protection Class	IP64 Dust-tight and Protected against splashing water.
Dimensions & Weight	17×9×4cm, 270g (Main Unit only)

Digital Plato Refractometer PR-Plato

The PR-Plato is designed for breweries to measure the specific gravity of sweet wort in degrees Plato. Taking measurements with the PR-Plato only requires a few drops of sample, and it provides accurate readings within 3 seconds!

Specifications

Model	PR-Plato
Cat.No.	3429
Range	0.0 to 30.0%
Resolution	0.1%
Accuracy	±0.1°P
Temperature compensation	5 to 40℃
Power Supply	006P dry battery (9V)
Dimensions & Weight	17×9×4cm,270g
