THE BrixMeister ys

納期について

「15時までの注文で翌日出荷！」のアイコンが表示されている製品については、15時までにご注文とお支払いが確認できた場合、翌日出荷いたします。（土日祝および年末年始休暇を除きます）

■注意事項

×

World's First Hybrid

PAL-BX|SALT
PAL-BX|SALT

Brix and Salt Hybrid Meter

PAL-BX|SALT

SDGs

6 Reasons

Function & Design

PAL-BX|SALT

Optical prism and titanium dual electrode

PAL-BX|SALT+5

No reagents or glassware required

Anyone can measure easily

Brix

Measurement Method

Q&A

Aibou＝PAL　First was the anatomy of human hand that we studied extensively… PROCUCT CONCEPT

6 Reasons for choosing our Brix and Salt Hybrid Meter

Optical prism and titanium dual electrode

Optical prism and titanium dual electrode

A hybrid brix and salt meter born by the fusion of optics and metal.An optical prism is used for the concentration via light refraction, and titatanium for salt concentration via electrical conductivity.

Pursuing SDGs, it can withstand long-term use.

Pursuing SDGs, it can withstand long-term use.

The concept of `anyone`, `anywhere` and `easily` being able to measure has been our standard, but now we have added `for a long time` to our list for the strongest of specifications. Working towards sustainability, the PAL-BX/SALT is made of durable materials designed for long term use without worry.

World's first! Dilution-free Salt Measurement

World's first! Dilution-free Salt Measurement

Yes, I was looking for something like this!‘Not only providing the means to measure the balance between concentration and salt content in one unit, the decisive factor in taste for all food, with our proprietary algorithm we also took away the stress that comes with dilution.

No reagents or glassware required

No reagents or glassware required

Costly and hard to dispose of reagents were needed for the titration method. Glass hydrometers needed to be handled carefully in food facilities due to the danger of dropping and shattering glass. Now with the Brix and Salt Meter,, you don’t have to worry about reagents or damaged glass!

Anyone can measure easily

Anyone can measure easily

When using for the first time, a simple programming with 1 undiluted and 2 diluted versions of the sample is needed. After measuring the Brix and salt of the three samples, the user scale is automatically created from those values. From then on, that sample can be dropped on the unit and measured without any dilution!

It can be cleaned under running water.

It can be cleaned under running water.

Since is water resistant (IP65), it can be rinsed under running water after measurement. Highly viscous samples can also be rinsed with water..
This meter can withstand the harsh conditions in the kitchen or on the production line.

Setup Video Guide Setup Video Guide
Setup Video Guide Setup Video Guide

【PAL-BX|SALT】Applications

Soy Sauce・Miso

Sauce

Dressings・Mayonnaise

Pickles

Soup

Stewed dish・Oden

Rice

Bread

Boiling Water for Pasta

Butter

Cheese

Meat

Pickled Fish

Dried Fish

Roe

Fish Paste Products

Shellfish

Seaweeds

Seawater

Brine
For Cooking
For Agriculture

Onsen Tora-fugu・Koi

Model

New!
PAL-BX|SALT+5

With 5 user scales, No dilution required!

PAL-BX/SALT+5

New!
PAL-BX|SALT

Simple combination of Brix & Salt

PAL-BX/SALT

Function & Design

PAL™-BX | SALT + 5 Measurement Method
To prepare for measurement, press the heart key for 5 seconds or more to select the scale.

step1
step2
step3

QCan both the PAL-BX | SALT and PAL-BX | SALT + 5 measure salt content without dilution?

AOnly the PAL-BX | SALT + 5 has the user scale function to measure salt content without dilution


QHow many user scales can be registered on the PAL-BX/SALT +5?

AUp to 5 user scales can be registered.


QWhat is the user scale on the PAL-BX | SALT + 5?

AIt is function that allows samples with high Brix, like soy sauce, to be measured without dilution.


QWhat is the heart key?

APress the heart key to display the salt reduction index (salt concentration ÷ Brix).


QIs it possible to measure high temperature samples?

AIt is equipped with a temperature compensation feature to accurately measure high-temperature samples.


QHow should I store the unit ?

AIf the unit will not be used for a while, please store it in the original case it came in.

Product details

Digital Hand-held “Pocket” Brix-Salt Meter PAL-BX|SALT＋5

PAL-BX|SALT＋5 $650.00 USD
拡大画像
This is a hybrid of refractometer and salt meter which has an optical prism is used to measure the concentration (Brix) and titanium electrode is used to measure the salt contents.
It enables to check the balance between concentration(Brix) and salt that is the decisive factor for taste in foods in general.

In addition, we pursued the elimination of the dilution which is required for salt measurement especially for the concentrated samples like sauce.
Now, the salt concentration of samples with high concentration such as sauce can be measured without dilution.
Specifications
Model PAL-BX|SALT＋5
Cat.No. 4922
Scale Brix
Salt concentration
Range Brix : 0.00 to 90.0%
Salt concentration : 0.00 to 15.00％
Resolution Brix : 0.1％
Salt concentration : 0.01％
Accuracy Brix : ±0.2％
Displayed value : ±0.05％
(for salt concentration of 0.00 to 0.99%)
Relative precision : ±5％
(for salt concentration of 1.00 to 9.99%)
Relative precision : ±10％
(for salt concentration of 10.00 to 15.00%)
Power Supply 2 × AAA Batteries
International Protection Class IP65 Water resistant
Dimensions & Weight Main Unit : 55(W)×31(D)×109(H)mm, 100g

· NaCl Solution 2.50% (10mL) [*1] : RE-120250
PAL-BX|SALT＋5

Digital Hand-held “Pocket” Brix-Salt Meter PAL-BX|SALT＋5

Close

Digital Hand-held “Pocket” Brix-Salt Meter PAL-BX|SALT

PAL-BX|SALT $550.00 USD
拡大画像
This is a hybrid of refractometer and salt meter which has an optical prism is used to measure the concentration (Brix) and titanium electrode is used to measure the salt contents.

Furthermore, it equipped with an offset function to show the same value as other measurement methods.
Specifications
Model PAL-BX|SALT
Cat.No. 4921
Scale Brix
Salt concentration
Range Brix : 0.00 to 90.0%
Salt concentration : 0.00 to 15.00％
Resolution Brix : 0.1％
Salt concentration : 0.01％
Accuracy Brix : ±0.2％
Displayed value : ±0.05％
(for salt concentration of 0.00 to 0.99%)
Relative precision : ±5％
(for salt concentration of 1.00 to 9.99%)
Relative precision : ±10％
(for salt concentration of 10.00 to 15.00%)
Power Supply 2 × AAA Batteries
International Protection Class IP65 Water resistant
Dimensions & Weight Main Unit : 55(W)×31(D)×109(H)mm, 100g

· NaCl Solution 2.50% (10mL) [*1] : RE-120250
PAL-BX|SALT

Digital Hand-held “Pocket” Brix-Salt Meter PAL-BX|SALT

Close

Salt-meter PAL-SALT

PAL-SALT $360.00 USD
拡大画像
PAL-SALT is widely used in various industries for food and industrial solutions. For food products, in addition to checking salt content, salt meter is used to make sure salt is properly added and not forgotten for such product as bread, rice balls and frozen. For industrial use, salt meter is widely used for salt resistance test for cars and such.
*Offset feature use examples
#1. Program a dilution factor to display the original salt%
#2. Program a conversion factor to align the readings with titration methods.
Specifications
Model PAL-SALT
Cat.No. 4250
Scale Salt concentration (g/100g)
Temperature
Method Conductivity method
Range 0.00 to 10.0% (g/100g)
Resolution 0.01% for salt concentration of 0.00 to 2.99%
0.1% for salt concentration of 3.0 to 10.0%
Accuracy Displayed value ±0.05%
(for salt concentration of 0.00 to 0.99%)
Relative precision ±5%
(for salt concentration of 1.00 to 10.0%)

· PAL-CASE : RE-39409

· STRAP : RE-39410

· NaCl Solution 2.50% (10mL) [*1] : RE-120250

· Battery Case Cover With O-Ring : RE-38163

[*1] Calibration Certificate : Contact an ATAGO representative for details.

· USB Battery Charger : RE-34801
PAL-SALT

Salt-meter PAL-SALT

Close

Salt Meter PAL-SALT Mohr

PAL-SALT Mohr $360.00 USD
拡大画像
PAL-SALT Mohr gives a reading similar to those obtained from the Mohr’s method (titration). Like other ATAGO salt meters, PAL-SALT Mohr utilizes conductivity to measure samples. This unit also features an offset function which allows for readings to be compensated based on known standards.
Specifications
Model PAL-SALT Mohr
Cat.No. 4251
Scale Salt concentration (g/100mL)
Temperature
Method Conductivity method
Range 0.00 to 10.0% (g/100mL)
Resolution 0.01% for salt concentration of 0.00 to 2.99%
0.1% for salt concentration of 3.0 to 10.0%
Accuracy Displayed value ±0.05%
(for salt concentration of 0.00 to 0.99%)
Relative precision ±5%
(for salt concentration of 1.00 to 10.0%)

· PAL-CASE : RE-39409

· STRAP : RE-39410

· JORDAN for PAL(Silicon Cover) : RE-39414

· NaCl Solution 2.50% (10mL) [*1] : RE-120250

· Battery Case Cover With O-Ring : RE-38163

· USB Battery Charger : RE-34801

[*1] Calibration Certificate : Contact an ATAGO representative for details.

PAL-SALT Mohr

Salt Meter PAL-SALT Mohr

Close

Digital salt-meter ES-421

ES-421 $1,050.00 USD
拡大画像
The digital salt-meter, ES-421 employs a funnel-shaped sensor which measures the salt % of a sample such as the dilute solution of soy sauce, ketchup,mayonnaise, worcester sauce, squeezed juice of pickles, etc. It only needs 1.0ml of sample.*Improved durability with titanium electrodes.*Stage is made out of SUS316L.*Equipped with a backlight for even brighter, easier to read display.*Equipped with an “Offset Function.”*The NaCl solution for calibration is different from the solution used for the former ES-421(Cat.No4210).Its concentration has been changed from 2.84%→2.50%.
Specifications
Model ES-421
Cat.No. 4211
Scale Salt concentration (g/100g)
Temperature
Method Conductivity method
Range 0.00 to 10.0%
Resolution 0.01% for salt concentration of 0.00 to 2.99%
0.1% for salt concentration of 3.0 to 10.0%
Accuracy Displayed value ± 0.05% (for salt concentration of 0.00 to 0.99%)
Relative precision ± less than 5% (for salt concentration of 1.00 to 10.0%)
Ambient Temperature 10 to 40°C (Automatic Temperature Compensation)
Power Supply 006P Dry battery (9V)
Dimensions & Weight 17×9×4cm, 220g
(Main Unit only)

· NaCl Solution 2.50% (10mL) [*1] : RE-120250
ES-421

Digital salt-meter ES-421

Close

Fish fillet salinity meter PAL-Fish Fillets

PAL-Fish Fillets $580.00 USD
拡大画像

Renewal! New release of PAL-Fish Fillets

PAL-FM1 has been renewed and released as a new version, PAL-Fish Fillets - ideal for measuring both dried fish and raw fillets! It is now possible to measure closer to titration values and more precisely with a minimum error of 0.0%*! In addition, by expanding the temperature compensation range to 5 - 40 ﾟC, which is more in line with actual environmental site temperatures, measurements have become more stable. Insert the probe into the fillet and in just 3 seconds receive a value that is close to titration. For dried fish, it is recommended to measure in the abdomen area. PAL-Fish Fillets frees the user from the hassle and trouble of past methods!
* According to research. Results depend on the type and position of dried fish and raw fillets being measured.
Specifications
Model PAL-Fish Fillets
Cat.No. 4225
Scale Fish Salinity %
Temperature ﾟC
Range 0.0 to 10.0%
0.0 to 100 ﾟC
Resolution 0.1%
0.1 ﾟC
Accuracy Fish salinity% :
Absolute Precision ±0.1%(0.0 to 3.9%)
Relative Precision ±5%(4.0 to 10.0%)
* In the case of saline solution
±1ﾟC
Temperature compensation 5 to 40 ﾟC
Measurement Time About 1 second
Power Supply 2 × AAA Batteries
International Protection Class IP65 Water resistant
Dimensions & Weight Main Unit:55(W)×31(D)×109(H)mm
Electrode Probe : Φ10×110mm (Cable length : applox.400mm)

· PAL-CASE : RE-39409

· STRAP : RE-39410

· JORDAN for PAL(Silicon Cover) : RE-39414

· NaCl Solution 2.50% (10mL) [*1] : RE-120250

· NaCl Solution 2.5% (100mL) : RE-143025

· NaCl Solution 2.5% (500mL) : RE-145025

· Battery Case Cover With O-Ring : RE-38163

· USB Battery Charger : RE-34801

[*1] Calibration Certificate : Contact an ATAGO representative for details.

PAL-Fish Fillets

Fish fillet salinity meter PAL-Fish Fillets

Close

Salt-meter PAL-SALT PROBE

PAL-SALT PROBE $550.00 USD
拡大画像
The PAL-SALT PROBE features convenient operation of submerging the probe in a liquid for measuring the salt content in as fast as 3 seconds. The probe may be inserted directly into semi-solid food. However,measurements at different locations may be inconsistent,and such direct measurements may vary from measurements by dilution methods.
・Electrode pins have extended from 5mm to 10mm for easier measurement.
・Screen now features a backlight for an easier to read
Specifications
Model PAL-SALT PROBE
Cat.No. 4222
Scale Salt concentration (g/100g)
Method Conductivity method
Range 0.00 to 7.0%
Resolution 0.01% (0.00 to 1.99%)
0.1% (2.0 to 7.0%)
Accuracy ± 0.1% (0.00 to 1.99%)
Relative precision : ± 5% (2.1 to 5.0%)
Relative precision : ± 10% (5.1 to 7.0%)
Power Supply 2 × AAA Batteries
International Protection Class IP65 Water resistant
Dimensions & Weight Main Unit : 55(W)×31(D)×109(H)mm, 100g
Electrode probe : Φ15×570mm (Cable length : applox.400mm)

· Battery Case Cover With O-Ring : RE-38163

· USB Battery Charger : RE-34801

· Electrode Probe (for PAL-SALT PROBE) : RE-33096
PAL-SALT PROBE

Salt-meter PAL-SALT PROBE

Close

Seawater meter PAL-Fish Tank

PAL-Fish Tank $250.00 USD
拡大画像
This model is for measuring the salinity in seawater.
The only one model in the world adopt the titanium as an electrode.
It is resistant to scratches and has much durability.
Specifications
Model PAL-Fish Tank
Cat.No. 4121
Range Salinity:0.0 to 45.0‰
Minimum Scale 0.1‰
Accuracy ±2.0‰
Sample Volume 2 to 3 drops
Measurement Time About 3 seconds
Power Supply 2 × AAA Batteries
Battery Life About 11,000 measurements (When using AAA Batteries. About 1,500 times for PAL-S only)
International Protection Class IP65 Water resistant
Dimensions & Weight 5.5 × 3.1 × 10.9cm 100g (main unit only)

· Battery Case Cover With O-Ring : RE-38047

· USB Battery Charger : RE-34801

PAL-Fish Tank

Seawater meter PAL-Fish Tank
